70cc Dual-Cylinder Two-Stroke Air-Cooled Gasoline Engine with Electric Start for Fixed-Wing RC Aircraft

70cc Dual-Cylinder Two-Stroke Air-Cooled Gasoline Engine with Electric Start for Fixed-Wing RC Aircraft

Upgrade your RC flying experience with the NGH GTT70-E 70cc Horizontally Opposed Twin-Cylinder Two-Stroke Air-Cooled Gasoline Engine. Designed for fixed-wing RC airplanes, this powerhouse is packed with features that make it the ultimate choice for hobbyists and professionals alike.

Key Features:

• Low Noise Operation: Equipped with integrated welded exhaust pipes, the GTT70-E ensures a smooth exhaust flow, drastically reducing noise levels. Enjoy serene flights without sacrificing power!
• Front-Mounted Carburetor: Say goodbye to complicated adjustments! The front-mounted carburetor allows for easy tuning, providing reliable and consistent operation every time.
• Precision Engineering: Featuring meticulously forged connecting rods with needle bearings, this engine guarantees exceptional lubrication and durability, leading to longer engine life and a smoother flying experience.
• Advanced Ignition System: Experience precise and reliable ignition timing with the automatic advance dual-cylinder ignition system, specifically tailored for NGH engines, ensuring optimal performance on every flight.
• Premium Spark Plug & Bearings: The GTT70-E includes highly reliable CM-6 spark plugs and deep groove ball bearings for smooth operation and extended engine life, reducing maintenance time and maximizing your flying enjoyment.
• Lightweight Electric Starter: The brushless motor and electronic control of the electric starter make it easy to use and perfect for quick engine starts, so you can get into the air faster!

Background:

Crafted by NGH's expert engineers, the GTT70-E is an evolution of the GT35, featuring a compact structure, stunning aesthetics, and robust power. Perfect for RC planes with a takeoff weight of 10-15kg, this engine is also ideal for fixed-wing and vertical takeoff drones of similar weight. It boasts a wear-resistant ductile iron cylinder body that maintains an inner hole roundness tolerance within 0.01mm, far superior to aluminum alloy chromium-plated cylinders.

Specifications:

• Material: Metal
• Model: GTT70-E
• Displacement: 69.92cc (34.96cc x 2)
• Bore: 37.3mm
• Stroke: 32mm
• Practical Speed Range: 1600-8000rpm
• Output Power: 7.3HP at 8300rpm
• Tensile Force: 16.5kg
• Engine Weight: 2070g
• Igniter Weight: 160g
• Igniter Power Supply: DC 6V-14.4V 1000mAh
• Fuel: 92# Unleaded Gasoline + Fully Synthetic 2T Lubricant
• Lubrication Ratio: Gasoline: Lubricating Oil = 40:1
• Recommended Propeller Specifications: 23x8-10, 24x8-10 (Dual-blade)
• Product Weight: 2070g
• Package Dimensions: 25 x 25 x 25cm
• Package Weight: 3140g
• Packing: Box
• Ages: 16+

What's in the Box:

• Engine x1
• Exhaust Pipe x1
• Spark Plug x1
• CDI Ignition x1
• Mounting Bracket x1
• User Manual and Warranty Card x1

Don’t miss out on the chance to elevate your RC flying experience! Purchase the NGH GTT70-E today and take to the skies with confidence and power!
