KACIO LS3-13S Compact 3-Cylinder Reciprocating Steam Engine for Model Boats with Reverse Function
Experience the thrill of steam-powered innovation with the KACIO LS3-13S Compact 3-Cylinder Reciprocating Steam Engine. This meticulously crafted steam engine is designed for model boats ranging from 80 to 120 cm, offering exceptional functionality and captivating aesthetics.
Standout Features:
Sleek and Efficient Design: The LS3-13S boasts a simple yet elegant design, providing excellent performance without compromising on appearance. Its compact size and refined look make it a perfect addition to your steam model collection.
Durable Construction: Built with a precision casting base and surface electrophoresis treatment, this steam engine is engineered for longevity. The CNC finished parts ensure high precision and reliability, while the unique ladder frame structure enhances torsional resistance.
High-Temperature Resistant Sealing: The cylinder head is sealed with a 0.08mm red copper sheet, offering exceptional resistance to high temperatures and corrosion. The use of high hardness beryllium copper for the spindle bearing guarantees longer and more stable operation.
Oil Cup for Extended Lifespan: The integrated oil cup with an oil discharge function allows for easy maintenance. Each friction surface is well-lubricated, ensuring prolonged service life and optimal performance.
Versatile Operation: This steam engine supports both forward and reverse rotation, powered by a large diameter cylinder that provides robust torque for your propeller. Enhance your setup by pairing it with an efficient boiler and necessary valve accessories (not included).
Artistic Craftsmanship: With its mini and delicate shape, the KACIO LS3-13S is not just a mechanical component; it's a piece of art. Ideal for collectors and a fantastic gift for steam model enthusiasts aged 14 and up.
Specifications:
Material: Copper
Model: LS3-13S
Size: Base 48mm wide, 111mm long, 95mm high + 6mm thick sleepers
Cylinder Diameter: 14.0mm
Stroke: 12.0mm
Spindle Diameter: 5.0mm
Spindle Center Ground Height: 17.0mm
Operating Pressure: 0.05Mpa - 0.8Mpa
Recommended Air Pressure: 0.2Mpa - 0.6Mpa
Inlet Interface Thread: M6-0.5 1/4-40
Product Dimensions: 11.1 x 4.8 x 10.1 cm
Product Weight: 930g
Package Dimensions: 21 x 16 x 16 cm
Package Weight: 1200g
Packing: Box
Why Wait? Get Yours Now!
Unlock the power of steam and elevate your model boating experience today! Order the KACIO LS3-13S Steam Engine now and transform your steam model ships into remarkable works of art and engineering!
